Description
Technical Specifications
General Information
| Model Number | B687 |
|---|---|
| Color | Black |
| Expandability | Memory |
Operating System
| Operating System | Windows 11 Pro |
|---|
Case & Motherboard
| Computer Case | PowerSpec SFF 208 |
|---|---|
| Case Orientation | Vertical |
| Motherboard | ASUS Prime H610M-A WiFi D4 |
| Chipset | Intel H610 |
Processor (CPU)
| CPU Part Number | CM8071504821112 |
|---|---|
| CPU Model | 14th Generation Core i5 Processor |
| Turbo Boost Speed | Up to 4.7GHz |
| CPU Summary | Intel Core i5 14400 (1.8GHz) |
| CPU Socket | FCLGA1700 |
| CPUs Installed | 1 |
| CPUs Supported | 1 |
| CPU Core | Raptor Lake |
| Cores | Ten-Core |
| Performance Cores | 6 @ 2.5 GHz Base, 4.7 GHz Turbo |
| Efficient Cores | 4 @ 1.8 GHz Base, 3.5 GHz Turbo |
| CPU Threads | 16 Threads |
| Smart Cache | 20MB |
| CPU Main Features | Intel Turbo Boost Technology 2.0 |
Memory (RAM)
| Total Memory | 16GB |
|---|---|
| Memory Speed | DDR4-2666 |
| Memory Slots (Total) | 2 |
| Form Factor | 288-pin DIMM |
| Maximum Memory Supported | 64GB |
Solid State Drive
| SSD Interface | NVMe |
|---|---|
| SSD Capacity | 500GB |
Display
| Display Type | Display Not Included |
|---|---|
| Webcam | No |
Graphics/Video
| GPU Type | Intel UHD Graphics 730 |
|---|---|
| Video Memory | Shared |
| GPU Interface | Integrated |
Audio
| Audio System | Realtek Surround Sound High Definition Audio CODEC |
|---|---|
| Audio Channels | 7.1 |
Communications
| LAN | Gigabit LAN |
|---|---|
| LAN Data Rate Speed | 10/100/1000Mbps |
| WLAN | Wireless LAN WiFi 5 (802.11ac) |
| Bluetooth | Bluetooth 5.0 |
| Wireless Technology | 802.11a 802.11b 802.11g WiFi 5 (802.11ac) WiFi 4 (802.11n) |
Front/Top Panel Ports
| USB 3.1 | 2 x USB 3.2 (Gen 1 Type-A) |
|---|---|
| Audio | 1 x headphone 1 x microphone |
Back Panel Ports
| USB 3.1 | 2 x USB 3.2 (Gen 2 Type-A) |
|---|---|
| USB 2.0 | 4 x USB 2.0 (Type-A) |
| HDMI | 1 |
| DisplayPort | 1 |
| LAN RJ-45 | 1 |
| Audio | 3 |
Expansion Slots
| PCIe x16 Slots (Total) | 1 |
|---|---|
| PCIe x16 Slots (Available) | 1 |
| PCIe x1 Slots (Total) | 1 |
| PCIe x1 Slots (Available) | 1 |
Keyboard
| Keyboard | Standard |
|---|
Mouse
| Buttons | 3 |
|---|---|
| Mouse | Optical |
| Connection Type | USB |
| Power Source | USB |
Power
| Power Range | 115VAC; 60hz; 10A |
|---|---|
| Power Supply | 250 Watt |
| Combined +12V Rating | 250 Watts |
Physical Specifications
| Width | 3.75 in. (95.25 mm) |
|---|---|
| Depth | 12.00 in. (304.80 mm) |
| Height | 13.00 in. (330.20 mm) |
| Box Dimensions (WxDxH) | 18.50 x 7.50 x 15.75 in. (469.90 x 190.50 x 400.05 mm) |
Package Contents
| What's in the Box | B687 Desktop Computer, Power Cord, Mouse, Keyboard, Quick Start Guide, Warranty Sheet |
|---|---|
| Preloaded Software | Microsoft Office 365 Trial |
Warranty
| Parts | 1 Year Limited |
|---|---|
| Labor | 1 Year Limited |
