Description
Technical Specifications
General Information
| Series | Aspire |
|---|---|
| Model Number | DT.BV5AA.001 |
| Color | Black |
| Expandability | Memory 2.5″ Drive 3.5″ Drive 5.25″ Drive |
Operating System
| Operating System | Windows 11 Home |
|---|
Case & Motherboard
| Case Orientation | Vertical |
|---|
Processor (CPU)
| CPU Model | AMD Ryzen 7000 Series Processor |
|---|---|
| Turbo Boost Speed | Up to 4.3GHz |
| CPU Summary | AMD Ryzen 5 7430U (2.3GHz) |
| CPU Socket | FP6 |
| CPUs Installed | 1 |
| CPUs Supported | 1 |
| CPU Core | Barcelo R |
| Cores | Six-Core |
| Graphics Cores | 7 @ 1800 MHz |
| CPU Threads | 12 Threads |
| Level 2 Cache | 3MB |
| Level 3 Cache | 13.75MB |
| CPU Main Features | AMD Enhanced Virus Protection (NX bit) |
Memory (RAM)
| Total Memory | 16GB |
|---|---|
| Memory Speed | DDR4-3200 |
| Memory Configuration | 1 x 16GB |
| Memory Slots (Total) | 2 |
| Memory Slots (Available) | 1 |
| Maximum Memory Supported | 32GB |
Solid State Drive
| SSD Interface | PCIe M.2 |
|---|---|
| SSD Capacity | 1TB |
Display
| Display Type | Display Not Included |
|---|---|
| Webcam | No |
Graphics/Video
| GPU Type | AMD Radeon Graphics |
|---|---|
| Video Memory | Shared |
| GPU Interface | Integrated |
Audio
| Audio System | High Definition Audio |
|---|
Communications
| LAN | Gigabit LAN |
|---|---|
| LAN Data Rate Speed | 10/100/1000Mbps |
| WLAN | 2×2 Wi-Fi 6E 802.11ax |
| Bluetooth | Bluetooth 5.3 |
| Wireless Technology | 802.11a 802.11b 802.11g WiFi 5 (802.11ac) WiFi 4 (802.11n) WiFi 6 (802.11ax) WiFi 6E (802.11ax) |
Front/Top Panel Ports
| USB 3.1 | 1 x USB 3.2 (Gen 1 Type-C) 1 x USB 3.2 (Gen 1 Type-A) |
|---|---|
| Audio | 2 x Audio |
Back Panel Ports
| USB 3.1 | 2 x USB 3.2 (Gen 1 Type-A) |
|---|---|
| USB 2.0 | 2 x USB 2.0 (Type-A) |
| HDMI | 1 |
| DisplayPort | 1 |
| LAN RJ-45 | 1 |
| Audio | 2 |
Expansion Bays
| External 5.25″ Bays (Available) | 1 |
|---|---|
| External 5.25″ Bays (Total) | 1 |
| Internal 2.5″ Bays (Total) | 1 |
| Internal 2.5″ Bays (Available) | 1 |
Expansion Slots
| PCIe x4 Slots (Total) | 1 |
|---|---|
| PCIe x4 Slots (Available) | 1 |
| M.2 | 2 Slots, 0 Available |
Keyboard
| Keyboard | USB |
|---|
Mouse
| Mouse | USB |
|---|
Power
| Power Supply | 90 Watt External Adapter |
|---|
Physical Specifications
| Width | 3.94 in. (100.08 mm) |
|---|---|
| Depth | 12.99 in. (329.95 mm) |
| Height | 11.61 in. (294.89 mm) |
| Weight | 8.82 lbs. (4.00 kg) |
| Box Dimensions (WxDxH) | 7.48 x 19.60 x 15.59 in. (189.99 x 497.84 x 395.99 mm) |
| Shipping Weight | 13.49 lbs. (6.12 kg) |
Package Contents
| What’s in the Box | Aspire XC-1725_BARR-UR13 Desktop Computer, USB Keyboard and USB Mouse, 90W AC Adapter & Power Cord |
|---|---|
| Preloaded Software | Microsoft Office trial McAfee Security Trial |
Warranty
| Parts | 1 Year Limited |
|---|---|
| Labor | 1 Year Limited |
