Description
Technical Specifications
General Information
| Platform | Notebook PC |
|---|---|
| Series | Titan |
| Model Number | 9S7-182411-1240 |
| Color – Lid | Core Black |
Operating System
| Operating System | Windows 11 Pro |
|---|
Processor (CPU)
| CPU Brand | Intel |
|---|---|
| CPU Model | Series 2 Core Ultra Processor |
| CPU Type | Core Ultra 9 |
| CPU Speed | 290HX Plus (1.8GHz) |
| Turbo Boost Speed | Up to 5.5GHz |
| CPU Core | Arrow Lake |
| Cores | Twenty-Four-Core |
| Performance Cores | 8 @ 2.7 GHz Base, 5.5 GHz Turbo |
| Efficient Cores | 16 @ 1.8 GHz Base, 4.7 GHz Turbo |
| CPU Threads | 24 Threads |
| Smart Cache | 36MB |
| CPU Main Features | Turbo Boost Max Technology 3.0 |
Neural Processor (NPU)
| Neural Processing Unit | Intel AI Boost |
|---|---|
| NPU Performance | Up to 13 TOPS |
Memory (RAM)
| Total Memory | 64GB |
|---|---|
| Memory Type | DDR5 |
| Memory Speed | DDR5-6400 |
| Form Factor | 262-pin SO-DIMM |
| Memory Slots (Total) | 2 |
| Memory Slots (Available) | 0 |
| Maximum Memory Supported | 96GB |
| Memory Configuration | 2 x 32GB |
Solid State Drive
| SSD Interface | NVMe Gen5x4 |
|---|---|
| SSD Capacity | 2TB |
| SSD Configuration | 1 x 2TB |
Display
| Screen Size | 18″ |
|---|---|
| Display Type | Ultra HD+ Mini LED |
| Resolution | 3840×2400 |
| Refresh Rate | 120Hz |
| Widescreen | Yes |
| Front Camera | Yes |
| Front Camera Resolution | 1080p |
| Front Camera Features | Full HD IR Privacy Shutter |
| Touch Screen | No |
Graphics/Video
| Graphics Card Features | Super Resolution Ray Reconstruction Frame Generation DLAA Multi Frame Generation DLSS 4.5 Dynamic Multi Frame Generation |
|---|---|
| GPU Type | NVIDIA GeForce RTX 5090 |
| Graphics/Video Memory | 24GB GDDR7 |
| VR Ready | Yes |
Audio
| Audio System | Sound by Dynaudio |
|---|---|
| Speakers | 4 x 2W Speakers 2 x 2W Woofer |
| Built-in Microphone | Array Microphone |
Communications
| Connectivity | WiFi+LAN |
|---|---|
| LAN | 2.5Gb LAN |
| LAN Data Transfer Rate | 10/100/1000/2500Mbps |
| WLAN | Killer Wireless LAN WiFi 7 BE1750 |
| Wireless Technology | 802.11b 802.11g 802.11a WiFi 5 (802.11ac) WiFi 4 (802.11n) WiFi 6 (802.11ax) WiFi 6E (802.11ax) WiFi 7 (802.11be) |
| Bluetooth | Bluetooth 5.4 |
Card Reader
| Media Supported | UHS-III Secure Digital |
|---|---|
| Memory Card Reader | Memory Card Reader |
Expansion
| Expandability | Memory |
|---|
Ports & Connectors
| Audio Ports | 3.5mm Combo x1 |
|---|---|
| Thunderbolt Ports | Thunderbolt 5 x2 |
| USB 3.1 | 3 x USB 3.2 (Gen 2 Type-A) |
| HDMI | 1 |
Security
| Physical Device Security | Kensington Lock Slot |
|---|---|
| System Security | Trusted Platform Module 2.0 |
Keyboard & Mouse
| Keyboard Features | Backlit Keyboard |
|---|---|
| Keyboard | Cherry Mechanical KB SteelSeries per-Key RGB (99 Key) |
| Mouse Type | Seamless EGB Haptic Touchpad |
Power
| Power Supply | 400 Watt AC Adapter |
|---|---|
| Battery | 4-Cell Li-ion |
Environmental Specifications
| Energy Star Compliant | Yes |
|---|
Physical Specifications
| Width | 15.90 in. (403.86 mm) |
|---|---|
| Depth | 12.08 in. (306.83 mm) |
| Height | 1.26 in. (32.00 mm) |
| Weight | 7.93 lbs. (3.60 kg) |
| Box Dimensions (WxDxH) | 13.97 x 17.99 x 4.01 in. (354.84 x 456.95 x 101.85 mm) |
What’s in the Box
| What’s in the Box | Titan 18 HX A2WJ-1240US 18″ Gaming Laptop Computer Platinum Collection, Power Cord |
|---|
Warranty
| Parts | 1 Year Limited |
|---|---|
| Labor | 1 Year Limited |
