Description
Product Information
SKU
005108
Mfr Part#
83EY006QUS
UPC
199275171628
General Information
Platform
Notebook PC
Series
Legion
Model Number
83EY006QUS
Color – Lid
Eclipse Black
Operating System
Operating System
Windows 11 Home
Processor (CPU)
CPU Brand
Intel
CPU Model
Series 2 Core Ultra Processor
CPU Type
Core Ultra 9
CPU Speed
290HX Plus (1.8GHz)
Turbo Boost Speed
Up to 5.5GHz
CPU Core
Arrow Lake
Cores
Twenty-Four-Core
Performance Cores
8 @ 2.7 GHz Base, 5.5 GHz Turbo
Efficient Cores
16 @ 1.8 GHz Base, 4.7 GHz Turbo
CPU Threads
24 Threads
Smart Cache
36MB
CPU Main Features
Turbo Boost Max Technology 3.0
Neural Processor (NPU)
Neural Processing Unit
Intel AI Boost
NPU Performance
Up to 13 TOPS
Memory (RAM)
Total Memory
64GB
Memory Type
DDR5
Memory Speed
DDR5-5200
Form Factor
262-pin SO-DIMM
Memory Slots (Total)
4
Memory Slots (Available)
2
Maximum Memory Supported
192GB
Memory Configuration
2 x 32GB
Solid State Drive
SSD Interface
M.2
SSD Capacity
2TB
SSD Configuration
1 x 2TB
Display
Screen Size
18″
Display Type
WQXGA IPS Display
Resolution
2560×1600
Refresh Rate
240Hz / 440Hz
Widescreen
Yes
Front Camera
Yes
Front Camera Resolution
5.0 Megapixel
Front Camera Features
IR
E-Shutter
E-Shutter
Touch Screen
No
Brightness
520 nits
Graphics/Video
Graphics Card Features
OpenGL 4.6
DirectX 12 Ultimate
Super Resolution
Ray Reconstruction
Frame Generation
DLAA
Multi Frame Generation
Vulkan 1.4
DLSS 4.5
Dynamic Multi Frame Generation
DirectX 12 Ultimate
Super Resolution
Ray Reconstruction
Frame Generation
DLAA
Multi Frame Generation
Vulkan 1.4
DLSS 4.5
Dynamic Multi Frame Generation
GPU Type
NVIDIA GeForce RTX 5080
Graphics/Video Memory
16GB GDDR7
VR Ready
Yes
Audio
Audio System
Nahimic Audio
Speakers
2 x 2W Speakers + 4 x 2W Woofer
Built-in Microphone
Dual Array Microphone
Communications
Connectivity
WiFi+LAN
LAN
2.5Gb LAN
LAN Data Transfer Rate
10/100/1000/2500Mbps
WLAN
Wireless LAN Wifi 7 (802.11be)
Wireless Technology
802.11b
802.11g
802.11a
WiFi 5 (802.11ac)
WiFi 4 (802.11n)
WiFi 6 (802.11ax)
WiFi 6E (802.11ax)
WiFi 7 (802.11be)
802.11g
802.11a
WiFi 5 (802.11ac)
WiFi 4 (802.11n)
WiFi 6 (802.11ax)
WiFi 6E (802.11ax)
WiFi 7 (802.11be)
Bluetooth
Bluetooth 5.4
Card Reader
Media Supported
SD
Memory Card Reader
Memory Card Reader
Expansion
Expandability
Memory
Ports & Connectors
Audio Ports
3.5mm Combo x1
USB 3.1
1 x USB 3.2 (Gen 2 Type-C)
3 x USB 3.2 (Gen 2 Type-A)
3 x USB 3.2 (Gen 2 Type-A)
Thunderbolt Ports
Thunderbolt 5 x2
HDMI
1
Security
System Security
Trusted Platform Module 2.0
Keyboard & Mouse
Keyboard Features
Backlit Keyboard
Keyboard
Per-key RGB Backlit, English
Mouse Type
Touchpad
Power
Power Supply
400 Watt AC Adapter
Battery
4-Cell Lithium-Ion
Battery Life
Up to 4 Hours (Stated battery Life is estimated based on manufacturers engineering testing for a new battery. Actual performance will vary based on notebook settings, environmental conditions, and usage. Battery capacity decreases over time and use.)
Physical Specifications
Width
15.87 in. (403.10 mm)
Depth
11.69 in. (296.93 mm)
Height
1.10 in. (27.94 mm)
Weight
7.70 lbs. (3.49 kg)
Box Dimensions (WxDxH)
25.39 x 14.29 x 4.33 in. (644.91 x 362.97 x 109.98 mm)
What’s in the Box
What’s in the Box
Legion 9i 18″ Gaming Laptop Computer, User Guide, 400W Slim Tip Charger
Preloaded Software
Microsoft Office 365 30-Day Trial
McAfee LiveSafe 30-Day Trial
McAfee LiveSafe 30-Day Trial
Warranty
Parts
1 Year Limited
Labor
1 Year Limited
