Description
Technical Specifications
General Information
| Platform | Notebook PC |
|---|---|
| Series | Legion |
| Model Number | 83EY006QUS |
| Color – Lid | Eclipse Black |
Motherboard
| North Bridge Chipset | Intel HM870 |
|---|
Operating System
| Operating System | Windows 11 Home |
|---|
Processor (CPU)
| CPU Brand | Intel |
|---|---|
| CPU Model | Series 2 Core Ultra Processor |
| CPU Type | Core Ultra 9 |
| CPU Speed | 290HX Plus (1.8GHz) |
| Turbo Boost Speed | Up to 5.5GHz |
| CPU Core | Arrow Lake |
| Cores | Twenty-Four-Core |
| Performance Cores | 8 @ 2.7 GHz Base, 5.5 GHz Turbo |
| Efficient Cores | 16 @ 1.8 GHz Base, 4.7 GHz Turbo |
| CPU Threads | 24 Threads |
| Smart Cache | 36MB |
| CPU Main Features | Turbo Boost Max Technology 3.0 |
Neural Processor (NPU)
| Neural Processing Unit | Intel AI Boost |
|---|---|
| NPU Performance | Up to 13 TOPS |
Memory (RAM)
| Total Memory | 64GB |
|---|---|
| Memory Type | DDR5 |
| Memory Speed | DDR5-5200 |
| Form Factor | 262-pin SO-DIMM |
| Memory Slots (Total) | 4 |
| Memory Slots (Available) | 2 |
| Maximum Memory Supported | 192GB |
| Memory Configuration | 2 x 32GB |
Solid State Drive
| SSD Interface | M.2 |
|---|---|
| SSD Capacity | 2TB |
| SSD Configuration | 1 x 2TB |
Display
| Screen Size | 18″ |
|---|---|
| Display Type | WQUXGA IPS Display |
| Display Finish | Glossy |
| Resolution | 3840×2400 |
| Refresh Rate | 240Hz / 440Hz |
| Widescreen | Yes |
| Front Camera | Yes |
| Front Camera Resolution | 5.0 Megapixel |
| Front Camera Features | IR E-Shutter |
| Touch Screen | No |
| Brightness | 520 nits |
Graphics/Video
| Graphics Card Features | OpenGL 4.6 DirectX 12 Ultimate Super Resolution Ray Reconstruction Frame Generation DLAA Multi Frame Generation Vulkan 1.4 DLSS 4.5 Dynamic Multi Frame Generation |
|---|---|
| GPU Type | NVIDIA GeForce RTX 5080 |
| Graphics/Video Memory | 16GB GDDR7 |
| VR Ready | Yes |
Audio
| Audio System | Nahimic Audio |
|---|---|
| Speakers | 2 x 2W Speakers + 4 x 2W Woofer |
| Built-in Microphone | Dual Array Microphone |
Communications
| Connectivity | WiFi+LAN |
|---|---|
| LAN | 2.5Gb LAN |
| LAN Data Transfer Rate | 10/100/1000/2500Mbps |
| WLAN | Wireless LAN Wifi 7 (802.11be) |
| Wireless Technology | 802.11b 802.11g 802.11a WiFi 5 (802.11ac) WiFi 4 (802.11n) WiFi 6 (802.11ax) WiFi 6E (802.11ax) WiFi 7 (802.11be) |
| Bluetooth | Bluetooth 5.4 |
Card Reader
| Media Supported | SD |
|---|---|
| Memory Card Reader | Memory Card Reader |
Expansion
| Expandability | Memory |
|---|
Ports & Connectors
| Audio Ports | 3.5mm Combo x1 |
|---|---|
| USB 3.1 | 1 x USB 3.2 (Gen 2 Type-C) 3 x USB 3.2 (Gen 2 Type-A) |
| Thunderbolt Ports | Thunderbolt 5 x2 |
| HDMI | 1 |
Security
| System Security | Trusted Platform Module 2.0 |
|---|
Keyboard & Mouse
| Keyboard Features | Backlit Keyboard |
|---|---|
| Keyboard | Per-key RGB Backlit, English |
| Mouse Type | Touchpad |
Power
| Power Supply | 400 Watt AC Adapter |
|---|---|
| Battery | 4-Cell Lithium-Ion |
| Battery Life | Up to 4 Hours (Stated battery Life is estimated based on manufacturers engineering testing for a new battery. Actual performance will vary based on notebook settings, environmental conditions, and usage. Battery capacity decreases over time and use.) |
Physical Specifications
| Width | 15.87 in. (403.10 mm) |
|---|---|
| Depth | 11.69 in. (296.93 mm) |
| Height | 1.10 in. (27.94 mm) |
| Weight | 7.70 lbs. (3.49 kg) |
| Box Dimensions (WxDxH) | 25.39 x 14.29 x 4.33 in. (644.91 x 362.97 x 109.98 mm) |
What’s in the Box
| What’s in the Box | Legion 9i 18″ Gaming Laptop Computer, User Guide, 400W Slim Tip Charger |
|---|---|
| Preloaded Software | Microsoft Office 365 30-Day Trial McAfee LiveSafe 30-Day Trial |
Warranty
| Parts | 1 Year Limited |
|---|---|
| Labor | 1 Year Limited |
