Description
Product Information
SKU
865733
Mfr Part#
BH0J0AA#ABA
UPC
199251105432
General Information
Series
Omni
Model Number
BH0J0AA#ABA
Color
Meteor Silver
Expandability
Memory
Operating System
Operating System
Windows 11 Home
Case & Motherboard
Case Orientation
Vertical
Processor (CPU)
CPU Model
14th Generation Core i7 Processor
Turbo Boost Speed
Up to 5.4GHz
CPU Summary
Intel Core i7 14700 (1.5GHz)
CPU Socket
FCLGA1700
CPUs Installed
1
CPUs Supported
1
CPU Core
Raptor Lake
Cores
Twenty-Core
Performance Cores
8 @ 2.1 GHz Base, 5.3 GHz Turbo
Efficient Cores
12 @ 1.5 GHz Base, 4.2 GHz Turbo
CPU Threads
28 Threads
Level 2 Cache
28MB
Smart Cache
33MB
CPU Main Features
Intel vPro Technology
Memory (RAM)
Total Memory
32GB
Memory Speed
DDR5-5600
Memory Configuration
2 x 16GB
Memory Slots (Total)
2
Memory Slots (Available)
0
Form Factor
288-pin DIMM
Maximum Memory Supported
64GB
Solid State Drive
SSD Interface
PCIe NVMe Gen 4 M.2
SSD Capacity
1TB
Display
Display Type
Display Not Included
Webcam
No
Graphics/Video
GPU Type
Intel UHD Graphics 770
Video Memory
Shared
GPU Interface
Integrated
Communications
LAN
Gigabit LAN
LAN Data Rate Speed
10/100/1000Mbps
WLAN
2×2 Wi-Fi 6 802.11ax
Bluetooth
Bluetooth 5.4
Wireless Technology
802.11a
802.11b
802.11g
WiFi 5 (802.11ac)
WiFi 4 (802.11n)
WiFi 6 (802.11ax)
802.11b
802.11g
WiFi 5 (802.11ac)
WiFi 4 (802.11n)
WiFi 6 (802.11ax)
Front/Top Panel Ports
USB 3.1
1 x USB 3.2 (Gen 2 Type-C)
3 x USB 3.2 (Gen 1 Type-A)
3 x USB 3.2 (Gen 1 Type-A)
Audio
1 x Headphone/Microphone Combo
Back Panel Ports
USB 2.0
4 x USB 2.0 (Type-A)
HDMI
1
DisplayPort
1
LAN RJ-45
1
Expansion Slots
PCIe x16 Slots (Total)
1
PCIe x16 Slots (Available)
1
PCIe x1 Slots (Total)
1
PCIe x1 Slots (Available)
1
M.2
2 Slots, 0 Available
Keyboard
Keyboard
USB
Mouse
Mouse
USB
Power
Power Supply
180 Watt 80 PLUS Gold
Environmental Specifications
Energy Star Compliant
Yes
EPEAT Compliant
Yes
Security
Physical Device Security
Kensington Lock Slot
Padlock
Padlock
Physical Specifications
Width
6.10 in. (154.94 mm)
Depth
13.27 in. (337.06 mm)
Height
12.40 in. (314.96 mm)
Weight
12.72 lbs. (5.77 kg)
Box Dimensions (WxDxH)
15.75 x 19.65 x 11.30 in. (400.05 x 499.11 x 287.02 mm)
Shipping Weight
19.89 lbs. (9.02 kg)
Package Contents
What’s in the Box
OmniDesk M02-0031 Desktop Computer, HP USB Keyboard and Mouse Combo
Preloaded Software
McAfee 30-Day Trial
Warranty
Parts
1 Year Limited
Labor
1 Year Limited
