Description
Product Information
SKU
871442
Mfr Part#
RFJMM
UPC
884116479666
General Information
Series
Pro Slim
Model Number
RFJMM
Color
Black
Expandability
Memory
Operating System
Operating System
Windows 11 Pro
Case & Motherboard
Case Orientation
Vertical
Chipset
Intel Q870
Processor (CPU)
CPU Model
Series 2 Core Ultra Processor
Turbo Boost Speed
Up to 5.3GHz
CPU Summary
Intel Core Ultra 7 265 (1.8GHz)
CPU Socket
FCLGA1851
CPUs Installed
1
CPUs Supported
1
CPU Core
Arrow Lake
Cores
Twenty-Core
Performance Cores
8 @ 2.4 GHz Base, 5.2 GHz Turbo
Efficient Cores
12 @ 1.8 GHz Base, 4.6 GHz Turbo
CPU Threads
20 Threads
Smart Cache
30MB
CPU Main Features
Intel vPro Technology
Neural Processor (NPU)
Neural Processing Unit
Intel AI Boost
NPU Performance
Up to 13 TOPS
Memory (RAM)
Total Memory
16GB
Memory Configuration
1 x 16GB
Memory Slots (Total)
4
Memory Slots (Available)
3
Form Factor
288-pin UDIMM
Maximum Memory Supported
128GB
Solid State Drive
SSD Interface
PCIe 4.0 NVMe
SSD Capacity
512GB
Display
Display Type
Display Not Included
Webcam
No
Graphics/Video
GPU Type
Intel Graphics
Video Memory
Shared
GPU Interface
Integrated
Audio
Audio System
High Definition Audio
Communications
LAN
Gigabit LAN
LAN Data Rate Speed
10/100/1000Mbps
WLAN
Intel Wi-Fi 6E AX211
Bluetooth
Bluetooth 5.3
Wireless Technology
802.11a
802.11b
802.11g
WiFi 5 (802.11ac)
WiFi 4 (802.11n)
WiFi 6 (802.11ax)
WiFi 6E (802.11ax)
802.11b
802.11g
WiFi 5 (802.11ac)
WiFi 4 (802.11n)
WiFi 6 (802.11ax)
WiFi 6E (802.11ax)
Front/Top Panel Ports
USB 2.0
2 x USB 2.0 (Type-A)
USB 3.1
1 x USB 3.2 (Gen 2 Type-A)
1 x USB 3.2 (Gen 2×2 Type-C)
1 x USB 3.2 (Gen 2×2 Type-C)
Audio
1 x Headphone/Microphone Combo
Back Panel Ports
USB 3.1
1 x USB 3.2 (Gen 2 Type-C)
3 x USB 3.2 (Gen 1 Type-A)
3 x USB 3.2 (Gen 1 Type-A)
USB 2.0
2 x USB 2.0 (Type-A)
DisplayPort
3
LAN RJ-45
1
Expansion Slots
PCIe x16 Slots (Total)
1
PCIe x4 Slots (Total)
1
PCIe x1 Slots (Total)
1
M.2
4
Power
Power Supply
260 Watt
Environmental Specifications
Energy Star Compliant
Yes
Security
Physical Device Security
Padlock Ring
Kensington Security Cable Slot
Kensington Security Cable Slot
System Security
Trusted Platform Module 2.0
Physical Specifications
Width
3.70 in. (93.98 mm)
Depth
11.54 in. (293.00 mm)
Height
11.95 in. (303.53 mm)
Weight
14.51 lbs. (6.58 kg)
Box Dimensions (WxDxH)
10.50 x 19.40 x 15.60 in. (266.70 x 492.76 x 396.24 mm)
Package Contents
What’s in the Box
Pro Slim Plus QBS1250, Keyboard, Mouse, Quick Start Guide, System Power Cord (US), Documentation
Warranty
Parts
3 Years Limited / Onsite
Labor
3 Years Limited / Onsite
